Qingdao Jinhongrui Steel Structure Co., Ltd.
Prefabricated container house
Basic Info
| Model NO. | Steel Frame | ColorQ235Galvanized Steel Sheet 2.3mm |
| Wall Material | PU/EPS/Rock WoolSandwich Panel | Color | Light Silver Gray or White or Customerized |
| Door Material | Steel/Plastic Wood/Sandwich Panel | Connection | Screws,Bolts |
| Layout | According to Customer′s Design | Resistant Temperature | -20 to 50 Degree |
| Fire Proof | B2 Grade (Can Reach B1) | Trademark | JHR |
| Transport Package | Sea Worthy Packing | Specification | 20/40 Feet House |
| Origin | Shandong, China | HS Code | 94060000 |
Container homes is a standard mobile house. Stong steel structure makes it resist up to 120KM/H wind speed. Flat packing and loading into 40feet containers when shipping makes goods safe and easy to transport and lay in at local site.
Standard Accessory
| Item | Name | Description |
| Structure | Flatpack container | • Cold rolled steel structure with corner casts and forklift pockets 90x256x2050mm • Available size, 8ft x 10ft, 8ft x 16ft, 8ft x 20ft, 8ft x 24ft, 8ft x 30ft, 10ft x 20ft |
| Wall Panel | Exterior Cladding | • 0.5mm thick corrugated or flat galvanized coated steel sheet |
| Insulation | • EPS, rock wool, glass wool • 60mm, 70mm, 80mm, 100mm | |
| Internal Cladding | Laminated E1 - Emission Valued 9mm thick chipboard; • 0.5mm thick galvanized and coated color steel sheet. | |
| Floor | Floor Steel frame | • 3mm thick cold rolled & welded steel profiles; • Insulation Thickness: 100mm mineral wool(on option); • Subfloor: 0.5mm thick, galvanized steel sheet(on option); |
| Floor Board | 18mm magnesium(water resistant v 100); | |
| Flooring | PVC sheet, ready in factory | |
| Roof | Roof steel frame | • 4mm thick cold rolled & welded steel profiles |
| Roof Cover | 0.5mm thick galvanized sheet & double folded in the roof middle; | |
| Insulation | 50-100mm thickness rock wool | |
| Ceiling | 9mm chipboard(V20), White(Usual); 50mm 50mm Steel Sandwich panel(Option 1); | |
| Corner Posts | 4 sets | 3/4mm thick cold rolled & welded steel profiles, Screwed to the floor base frame and roof frame. |
| Door | External Door and Internal Door | • Alu door or Steel Security Door • Steel frame with triangular wrap-around sealing; • Right or left hand hinged; • Inward or outward opening; • Door blade with galvanized steel sheets on both sides; • Insulated with honeycomb; • Regular size: 870*2040mm, 870*1995mm. |
| Window | Window for room | PVC frame with insulated glazing • integrated Aluminum roller shutters(on option) • Color: white; • Tilt & turn mechanism or sliding; • Regular size: 800*1100mm. |
| Window for toilet | PVC frame with insulated glazing • Color: white; • Tilt & turn mechanism; • Regular size: 500*500mm. Or exhaust fan on option | |
| Electrical | Default: 2* tube light, 1* socket for AC, 2* socket for a charge, 1*switch, 1 distribute box. Available in CE, AS/NZ, UL. | |
| Plumping system |
Qingdao Jinhongrui Steel Structure Co., Ltd is an ISO 9001:2008 Certified manufacturer of Pre-engineered long-span steel structure frame building based in Qingdao, China, started 2000. Spread over 30,000sq meters and having fully atomatic machinery and high qualified design, engineering, fabrication & erection staff. It has 5 production line of H section steel with 20,000 T annual production, 2 production lines of C&Z section steel with 16,000T annual production, yearly production exceeds 2 milllion meters corrugated steel sheet and sandwich panel with 5 production lines.
The company has completed a series of large-scale steel structure projects with high quality, India power plant, Angola plank house, Mauritius market, Australia, Netherlands, Rwanda, etc Project.. our products are exported to Southeast Asia, Europe, Africa and other countries, leaving a good reputation in the same industry and customers.
The company attaches great importance to improving the management level of modern enterprises and establishing a scientific quality management system. It attaches great importance to the cultivation and use of talents.Relying on excellent management personnel, scientific and advanced technology and strong management advantages of raw materials of color coated steel plate, the company effectively promotes the continuous expansion of the market.Its products are based in Qingdao and exported to domestic and foreign markets.
With the management policy of "quality first, customer first" and the management philosophy of "pursuing excellent quality, dedication and sincere service", the company provides customers with valuable services.
Jinhongrui is geared up to handle all kinds of projects ( from small pre-engineeried steel structure building to complex long-span steel structural buildings). We are your one stop source for all the durable, affordable and completely versatile pre-engineered long-span steel structure frame building that will definitely put you at an advantageous position in the market as you can get your project up and running within the shortest possible time.
- Customized drawings design
- Competitive quotations
- Professional suggestions for a cost-effective solution
- Project installation instruction or supervision
We also guarantee:
Product Quality
JHR specializes in designing, manufacturing, processing and installing various steel structure projects since 2008. Also, we were awarded TOP CLASS qualification for steel structure production & contracting. All product should be checked quality from raw material, during production to before load. We make sure every part arrive in your hand are perfect.
On-time Shipment
JHR also guarantees on-time delivery time under our experienced workers and modern machine under good management.
All steel part and materials shall be packed carefully under full protection.
1.Q: Are you a factory or trading company?
A: Qingdao Jinhongrui Steel Structure Co., Ltd. is located in Qingdao City, Shandong Province.2. Q: What's your supply capacity?
A: we have various steel structure product, and annual Production for referring: container house 3000sets, prefab house 10,000square meters; steel structure 80,000 tons.
3.Q: Could you please design a new and unique prefab house for me?
A: Absolutely! We are able to provide you with not only construction scheme and structural drawings, but landscape design! Besides, detailed drawings and 3D models are surely included. One-stop service is our outstanding superiority with no doubt.
4.Q: What should I provide to build a steel prefab house?
A: So easy! Sketch drawing would be a better reference for us. However, you will never mind if you don't have any. Simply notify us of your requirements, such as the area, usage and the stories of the house. Before long, you'll possess an amazing design.
5.Q: How could I ensure the cost of building a steel prefab house?
A: Firstly, the designing scheme should be accepted. Then, the kinds of building materials should be confirmed since different types and qualities make various prices. After that, we will send you a detailed quotation.
6.Q: How Long does it take to build a prefab container house?
A: It depends on the size of the house. Generally, the construction period is a 1 container house by a construction team of 4 people. It only costs 4 hours to build a container house.
7.Q: Is it difficult to build a prefab house?
A: totally not, you can build the house independently according to the construction drawings as long as you know how to use an electric tool. Or I can provide a video show you how to fast install a house.
8.Q: Does this kind of house can only be used in a residential building?
A: Absolutely not. It can be used in all kinds of buildings, such as hotel, commercial office, school, entertainment club, light industrial workshop, etc.
9.Q: How long is your delivery time?
A: Generally it is within 15-30 days after getting the deposit and final drawing, definitely according to quantity and house style.
10.Q: Can I ask for the toilet, kitchen, decoration, solar heater and so on.
A: Absolutely! We are turnkey house solution supplier, we have an engineer to design the one stop house also reliable suppliers for those fittings.
11.Q: How can I get the quotation for the project?
A: If you have drawn, we can offer you our quotation according to your drawing. If you have no design, Our engineer makes your idea to a real house and will design some drawings for you to confirm. And then offer you a quotation under your material demand and drawing.
Pls, feel free to contact us for any question
